Highlight:
Household Power Station Charger
, Power Station Charger 16A
, Portable Electric Car Charger 3.5KW
Standby Power: |
3W |
Usage Scenarios: |
Indoor/Outdoor |
Working Humidity: |
5% -95% Non Condensing |
Working Temperature: |
-30℃～+50℃ |
Cooling Method: |
Gun Head IP67/control Box IP67 |
Safety Design: |
Undervoltage Protection, Overvoltage Protection, Overload Protection, Overcurrent Protection, Over Temperature Protection, Leakage Protection, Grounding Protection, Lightning Protection, Electrostatic Protection, Flame Retardant Protectionretardant Protect |
Household Power Station Charger Portable Electric Car Charger 3.5KW 16A
We usually export large quantities to foreign countries. Hope to find more trade partners.
HD-OB106 Portable Outdoor Power Station Charger, 3.5KW 16A, Low 3W Standby Power Loss
Product Description
1. Portable household portable charger
2. After charging and use, it can be carried with the vehicle
3. When the device is in standby mode, the power is as low as 3W, saving energy and low consumption
4. Three color charging indicator light, indicating charging related values
5. Numerical screen display, displaying real-time charging data of the charging gun
Describe
The HD-OB106 charging gun is a portable charging product that complies with the European Union's AC power consumption standards, with a rated maximum AC output power of 3.5KW and a weight of approximately 2KG. It is suitable for household new energy on-board chargers, outdoor travel, emergency relief, outdoor work, and other occasions.
General specifications
| Detailed parameters |
Parameter Details |
| Name and model |
HD-OB106 |
|
Appearance structure
|
plug model |
16A European standard plug |
| product type |
Plug and Charge |
| Shell material |
Gun Head - Control Box PC9330 |
|
Equipment size
|
Gun head 230 * 98 * 70mm/control box 220 * 98 * 62mm [H * W * D] |
| Installation method |
Floor/wall mounted |
| Install components |
Wall mounted screw accessories |
| Wiring method |
Up in and down out |
| Equipment weight |
About 2KG |
| Cable specifications |
3*2.5mm² +0.75mm² |
| Cable length |
5 meters [supports customized line length] |
|
Electrical indicators
|
input voltage |
AC230V |
| Input frequency |
50Hz/60Hz |
| maximum power |
3.5KW |
| output voltage |
AC230V |
| Output current |
16A |
| standby power |
3W |
|
Environmental indicators
|
usage scenarios |
Indoor/Outdoor |
| Working humidity |
5% -95% non condensing |
| working temperature |
-30℃～+50℃ |
| Working altitude |
<2000 meters |
| Protection level |
Gun head IP67/control box IP67 |
| Cooling method |
Natural cooling |
| Safety regulations and standards |
SAEJ1772 |
| Flame retardant grade |
UL94 V0 |
| Product Certification |
TUV,CE,CB |
|
Functional design
|
man-machine interface |
LCD 1.3 inch display screen/LED indicator light |
| communication interface |
/ |
| Packaging specifications |
Box gauge/weight |
505*505*298mm |
|
safety design
|
Undervoltage protection, overvoltage protection, overload protection, overcurrent protection, over temperature protection, leakage protection, grounding protection, lightning protection, electrostatic protection, flame retardant protectionretardant protection |
Application
Suitable for charging new energy vehicles anytime and anywhere for emergency electricity use in households, outdoor travel, emergency relief, outdoor work, and other occasions.
Plug over temperature protection
Specially designed to prevent the melting of household sockets and internal wires during electric vehicle charging due to high temperature, as well as the spontaneous combustion of internal wires, which may cause house fires, its advantages are self-evident.
When the car is charging, the controller screen displays the temperature of the plug end in real time.
