Highlight:
32A Portable Outdoor Power Station
, 8A Portable Outdoor Power Station
, outdoor power station Wall Mounted
8A-32A Portable Outdoor Power Station Floor / Wall Mounted
We usually export large quantities to foreign countries. Hope to find more trade partners.
Portable Outdoor Power Station HD-OB102 - 8A-32A Current Regulation & 0-8h Scheduled Charging
Product Description
1. Portable household portable charger
2. After charging and use, it can be carried with the vehicle
3. When the device is in standby mode, the power is as low as 3W, saving energy and low consumption
4. Three color charging indicator light, indicating charging related values
5. Numerical screen display, displaying real-time charging data of the charging gun
6.8A-10A-13A-16A-32A current gear adjustment, can be set to 0h-8h reservation charging function
Describe
The HD-OB102 charging gun is a portable charging product that meets the European Union's AC power consumption standards, with a rated AC output of maximum power of 7KW and a weight of approximately 3.4KG. It is suitable for household new energy on-board chargers, outdoor travel, emergency relief, outdoor work, and other occasions.
General specifications
| Detailed parameters |
Parameter Details |
| Name and model |
HD-OB102 |
|
Appearance structure
|
plug model |
32A industrial plug |
| product type |
Plug and play charging/scheduled charging/current regulation |
| Shell material |
Gun Head - Control Box PC9330 |
|
Equipment size
|
Gun head 240 * 98 * 70mm/control box 220 * 80 * 70mm [H * W * D] |
| Installation method |
Floor/wall mounted |
| Install components |
Wall mounted screw accessories |
| Wiring method |
Up in and down out |
| Equipment weight |
About 3.4KG |
| Cable specifications |
3.6mm² +0.75mm² |
| Cable length |
5 meters [supports customized line length] |
|
Electrical indicators
|
input voltage |
AC230V |
| Input frequency |
50Hz/60Hz |
| maximum power |
7KW |
| output voltage |
AC230V |
| Output current |
8A-10A-13A-16A-32A |
| standby power |
3W |
|
Environmental indicators
|
usage scenarios |
Indoor/Outdoor |
| Working humidity |
5% -95% non condensing |
| working temperature |
-30℃～+50℃ |
| Working altitude |
<2000 meters |
| Protection level |
Gun head IP67/control box IP67 |
| Cooling method |
Natural cooling |
| Safety regulations and standards |
SAEJ1772 |
| Flame retardant grade |
UL94 V0 |
| Product Certification |
TUV,CE,CB |
|
Functional design
|
man-machine interface |
LCD 1.3 inch display screen |
| communication interface |
/ |
| Packaging specifications |
Box gauge/weight |
505*505*298mm |
|
safety design
|
Undervoltage protection, overvoltage protection, overload protection, overcurrent protection, over temperature protection, leakage protection, grounding protection, lightning protection, electrostatic protection, flame retardant protectionretardant protection |
Application
Suitable for charging new energy vehicles anytime and anywhere for emergency electricity use in households, outdoor travel, emergency relief, outdoor work, and other occasions.
Waterproof body not afraid of rain
Waterproof grade "IP54",.
Easily face rain and prevent the intrusion of various splashing water, without any harmful effects.
